External Coil Reaction Kettle

Main Structure of External Coil Reaction Kettle

The external coil reaction kettle mainly consists of reactor body, external coil, heat transfer medium, stirrer, inlet port, outlet port, exhaust port, thermometer, manometer and so on. The reactor body is usually made of stainless steel and other high-temperature-resistant materials, with good corrosion resistance and pressure resistance. The external coil, on the other hand, is a pipe that injects heat transfer medium (such as hot oil) into the outside of the reactor, through which heat transfer and exchange with the material inside the reactor takes place.

Features and Advantages of External Coil Reaction Kettle

1.Fast reaction speed: the external coil reactor adopts high temperature and high pressure reaction conditions, which makes the reaction speed increase greatly.
2.Uniform reaction: the stirrer can stir the materials in the reactor evenly to ensure the uniformity and adequacy of the reaction.
3.Easy operation: the operation of external coil reactor is relatively simple, only need to operate according to the set temperature and pressure.
4.Wide range of application: the external coiled tube reactor can be used for various chemical reactions with a wide range of applications, such as petroleum, chemical, rubber, pesticide, dyestuff, food, pharmaceutical intermediates and other industries.
5.High efficiency and stability: the external heat transfer method makes the reaction process more stable and efficient, and improves the production efficiency.
6.Energy saving: due to the higher heat transfer rate of external coil reactor, it can save more energy consumption and reduce cost.
7.Compact structure: the external coil reactor is more compact and delicate, which is more conducive to the display of the production workshop.
